Dispersers with Infinitely Variable Speed through Frequency Converter.

The HIGH SPEED Dispersers are used extensively in processing of newtonian products, where the saw tooth impeller works at high peripheral speed (up to 30 mt/sec) developing high shearing forces.

Installation

hoist mount or through the floor

• Strong mixing shaft, made of stainless steel, mounted on ball bearings
• Hydraulic raising and lowering of mixing head
• High sheer impeller, made of stainless steel, available in a wide range of sizes, from 200 up to 800mm (8" - 32").
• Pan fastening through adjustable band or chain for vessels of different sizes
• All safety devices in accordance with EC-Directives
• Motors totally enclosed or FLP
• Infinitely variable speed from 0 to maximum
• Vacuum cover
• Turning scraper
• Horse power from 15 to 220 h.p.

Vacuum is achieved through special seal between cover and pan edge. Light, inspection window and all necessary fittings are provided on the vacuum cover. Vacuum pump is chosen according to the properties of the mixing good and the required ultimate vacuum (normally rotary vane or liquid ring pumps). The impeller can be raised-lowered also by working under vacuum, in order to reach maximum dispersion and deaeration efficiency.

Under vacuum mixer with turning scraper The scraper is very strong and fitted with interchangeable blade, made of the most suitable material, according to the properties of the mixing good. Scraper is in most cases driven hydraulically and ever pushed against the pan walls
